AT89C51

microcomputer, 8-bit, DIP-40

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.80~1.10 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.80~1.10

PartNumber:: AT89C51

Brand:: ATMEL Corporation - ATMEL | Pack: DIP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Beryl Lucy Chen's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-06-12

From Other Seller

Part Number:AT89C51
US $0.80 - 1.10
HEF4051BT

US $0.15 - 1.20 / Piece
(0) Remove
BD9774HFP

US $0.70 - 1.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AT89C51 is a low-power, high-performance CMOS 8-bit microcomputer with 4K bytes of Flash Programmable and Erasable Read Only Memory (PEROM). The AT89C51 is manufactured using Atmel’s high density nonvolatile memory technology and is compatible with the industry standard MCS-51 instruction set and pinout.

Parametrics

AT89C51 absolute maximum ratings: (1)Operating Temperature: -55℃ to +125℃; (2)Storage Temperature: -65℃ to +150℃; (3)Voltage on Any Pin; (4)with Respect to Ground: -1.0V to +7.0V; (5)Maximum Operating Voltage: 6.6V; (6)DC Output Current: 15.0 mA.

Features

AT89C51 features: (1)Compatible with MCS-51?Products; (2)4K Bytes of In-System Reprogrammable Flash Memory-Endurance: 1,000 Write/Erase Cycles; (3)Fully Static Operation: 0 Hz to 24 MHz; (4)Three-Level Program Memory Lock; (5)128 x 8-Bit Internal RAM; (6)32 Programmable I/O Lines; (7)Two 16-Bit Timer/Counters; (8)Six Interrupt Sources; (9)Programmable Serial Channel; (10)Low Power Idle and Power Down Modes.
